232K-BB

$9.95$29.95

Waterproof Rocker Switch, 30 Amp DPDT 3-Position Momentary On-Off-Momentary On

Clear

Description

Waterproof Rocker Switch, 30 Amp DPDT 3-Position Momentary On-Off-Momentary On

Double pole, double throw 3 Position Momentary On-Off-Momentary On Rocker Switch. This switch spring returns to the center off position when the button is released. We have extensively tested this switch under harsh outdoor conditions and it performs very well. This heavy duty switch mounts in a .82 x 1.44 inch hole and it has 1/4 quick connect terminals. Internal gaskets and o-rings keep water & dust out of the contacts. Black body and button. Rated at 30A @ 12VDC, 18A @ 125VAC, 10A @ 250VAC.

Specifications

  • DPDT Momentary On-Off-Momentary On
  • Rated at 30A @ 12VDC, 18A @ 125VAC, 10A @ 250VAC.
  • Panel Cutout: .82″ x 1.44″
  • Waterproof to IP66

Additional information

Switch Type

Sealed Enclosure With Wire Leads, Standard

Downloads

232K-B/B Drawing PDF (187 KB)
