232K3-BB

$14.95

Waterproof Rocker Switch, 30 Amp Illuminated DPDT 3-Position Momentary On-Off-Momentary On

Description

Waterproof Rocker Switch, 30 Amp Illuminated DPDT 3-Position Momentary On-Off-Momentary On

Double pole, double throw 3 Position Momentary On-Off-Momentary On Rocker Switch. This waterproof, 10 terminal switch has two illuminated windows and provides 12 volt independent illumination. We have extensively tested this switch under harsh outdoor conditions and it performs very well. This heavy duty switch mounts in a .82 x 1.44 inch hole and it has 1/4 quick connect terminals. Internal gaskets and o-rings keep water & dust out of the contacts. Black body and button with one red and one amber lens. Rated at 30A @ 12VDC, 18A @ 125VAC, 10A @ 250VAC.

Specifications

  • DPDT Momentary On-Off-Momentary On
  • Rated at 30A @ 12VDC, 18A @ 125VAC, 10A @ 250VAC.
  • Panel Cutout: .82″ x 1.44″
  • Waterproof to IP66
  • UL,CSA & CE Approved

Downloads

232K3-B/B Drawing PDF (193 KB)
232K3-B/B Wiring Diagram PDF (17 KB)
